Trash Flow TFV-EC

Electric Trash Flow Dry Prime Pump

Electric driven dry prime pump.
  • Pump Size 3—30 inches
  • Max Head Up to 700 feet
  • Flow 100—44,000 US gpm

Literature



OPTIONAL INTELLIGENT CONTROL PANELS

Wastecorp control panels enable automated pump operation with minimal monitoring. This together with optional level control floats provides greater efficiency and productivity.

SKID MOUNTED OR TRAILER MOUNTED

Select from DOT compliant trailer mounted pump models with electric brakes and LED lighting packages or skid mounted. Either ships with a lifting bail for easy transportation around the job site

EASY MAINTENANCE, LONG LIFE CYCLES

Trash Flow components can be adjusted and replaced to renew pump performance. No disassembly or shim requirements are necessary.

ISO 9001 CERTIFIED TRASH PUMP MANUFACTURER

Wastecorp adheres to the highest quality pump manufacturing and reduced environmental regulations. The Trash Flow is ISO 9001 and ISO 14001 certified. The best part is, your Trash Flow is manufactured close to home.

Pump Specifications

Approx. Pump Operating Speed
1050 - 1550 RPM
Max. Discharge Head
110' (40 psi)
Max. Flow Capacity
450GPM - 12000 GPM
Max. Liquid Temperature
160°F (71°C)
Max. Suction Lift
25-720'
Solids Handling
3" Dia.
Suction/Discharge Size
6"

Materials of Construction

Bearing Housing
Grey Iron, ASTM A48; Class 30
Cover Plate
Grey Iron, ASTM A48; Class 30
Flapper Valves
Neoprene (w/ Internal Steel Weight)
Impeller
Ductile Iron ASTM A536, Grade 60-40-18 (Max. 12.38” OD)
Impeller Shaft
AISI 4140 HT
Pump Castings
Grey Iron, ASTM A48; Class 30
Seal Plate
Grey Iron, ASTM A48; Class 30
Wear Plate
SAE 1020 Steel

Standard Features

Mounting
* Trailer - Single Axle DOT compliant with e-brakes, fenders, lighting, swivel jack, ball hitch or pintel eye coupler * Fuel Tank - DOT Compliant 45 USG complete with fuel lines and mounting brackets * Optional Skid Mounted, Acoustic Enclosure
Standard Connection Type
ANSI #150 Flanged
