The Mud Sucker 2B-EC-DD Series is an electric double diaphragm pump with fluid handling capabilities up to 40 GPM. The pump
features check balls to manage heavier slurry and industrial fluid pumping. Electric motor options include single phase,
three phase and explosion proof. Select from stationary, mobile and a variety of control panel and variable frequency
ADVANCED BALL VALVE TECHNOLOGY
Wastecorp’s exclusive check balls designed to pump the tough stuff. Suction and discharge areas of the pump can be inspected
in seconds with the twist of a handle. Applications include general wastewater, septic waste, sewage, waste oil,
food processing waste and much more .
ELECTRIC DOUBLE DIAPHRAGM PUMP PROTECTION
The Mud Sucker 2B-EC-DD includes a standard emergency pressure relief valve. Since a diaphragm pump is also a positive displacement
pump, a pressure relief valve reduces the chances of damage in an over pressurization event.
PRODUCTIVITY ENHANCING ACCESSORIES
Genuine Mud Sucker accessories like wheel kits, trailer mounts, lifting bails, non-collapsible hoses, pump strainers are
also available for you 2FAC-EC-DD
STRONG PUMP SHAFTS
Stronger shafts designed for long life cycles.
SEVERAL DRIVE OPTIONS
Select from single or three phase electric, DC, or explosion proof pump motors. Drive options from the industry's top manufacturers
like SEW Eurodrive® and Siemens®
MUD SUCKER OPERATOR SAFETY
Ships complete with safety guards (removed in illustration above for clarity).
Select from several available options designed for the needs of your specific application.
HEAVY DUTY DIAPHRAGMS
Built to outlast. Wastecorp diaphragm accept the most punishing pumping conditions.
Energy Costs Savings
View Wastecorp's study comparing relative energy consumption costs of diaphragm pumps.
Accessories and Configurations
64349-00 Pump with Air Chambers
Standard Connection Type
Approx. Pump Operating Speed
2.5” Dia. Urethane with Steel Core
Siemens or SEW Eurodrive
Max. Discharge Head
50’ Vertical or 300’ Horizontal
Max. Liquid Temperature
140°F (60°C) continuous
Max. Suction Lift
20’ Vertical or 75’ Horizontal
Performance Range - Max. Capacity
2HP 3Ph TEFC Motor
Pump Specifications - Suction/Discharge Size
Pump Weight (Approx.)
1½” Dia. or 50% by Volume
Materials of Construction
AISI 12L14 Carbon Steel
7" OD Neoprene with Reinforcement
Aluminum A356, heat treated
AISI 12L14 Carbon Steel
Spare Parts Kits
63166-00 Basic Spare Parts Kit;
63165-00 Comp. Spare Parts Kit
